Graco Xtreme XL Airless Spray Pump


  • Uses Graco XL air motor – the largest motor ever built by Graco
  • 45:1 pump ratio
  • Mounted on a heavy duty cart
  • No paint feed hopper included – buy separately
  • High flow rate will handle multiple spray guns


The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before.

The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application. Discover all the benefits of a King sprayer here:

Additional information

Dimensions 103.51 × 65.41 × 129.54 cm

Document Downloads

King Brochure


Airless Spray Pump Introduction

Airless Spray Pumps and Coating Data Sheets

Flushing Paint Through Airless Spray Pump at Start-Up

Airless Spray Pump Start Up PT 1

Airless Spray Pump Start Up PT 2

Complete Strip Down and Rebuild Graco Xtreme Airless Spray Pump Lower

Replacement of Graco Xtreme Airless Spray Pump Piston Lower Packings
