DeFelsko PosiTector® Inspection Kits
DeFelsko PosiTector® Inspection Kits
DeFelsko PosiTector Pre-Configured Inspection Kits and Testex Inspection Kits are built for coating inspection work where you need to verify surface prep conditions and coating application results with one modular gauge body. These general-purpose kits are commonly used for jobsite QA/QC, shop inspection, and maintenance programs where coating thickness, surface profile, and environmental conditions need to be checked and documented.
- Designed for coatings inspection workflows such as surface prep verification, environmental monitoring, and dry film thickness measurement
- Includes a PosiTector gage body (Standard or Advanced) with probes and accessories in a hard shell carrying case
- Modular platform future-proofs your inspection capabilities with the same PosiTector body accepting a wide range of additional PosiTector probes when your needs grow
- Common kit configurations cover coating thickness, dew point and ambient conditions, and surface profile checks
- Choice of coating thickness probes available, based on expected thickness range requirements and whether ferrous (only) or ferrous and non-ferrous metals are being tested
- Choice of surface profile tools available, including either a direct-to-surface measurement probe or a replica tape digital micrometer package
- Choose from the pre-configured kit options on this page, or customize your kit with choice of additional probes
- Long Form Certificate of Calibration included, showing traceability to NIST or PTB
Live chat
Email
Phone
Online form DeFelsko PosiTector® Inspection Kits
Sku: P-IND6000KIT
DeFelsko PosiTector Inspection Kits are general purpose pre-configured inspection kits for coating thickness verification, environmental condition review, and surface profile measurement. They are built for the inspection steps most coating specs call out, thickness readings, dew point and climate checks, and profile documentation before and during coating work.
This kit family is available in over 20 configurations based on surface profile type, gage/body type, and substrate / coating thickness type .
Choose a standard DeFelsko PosiTector Pre-Configured Inspection Kit when you want direct surface profile readings using a PosiTector SPG surface profile probe. Choose a Positector Pre-Configured Testex inspection kit when you want tape based surface profile documentation using a Testex Digital Micrometer and replica tape, instead of an SPG probe.
Each kit also includes a choice of PosiTector gage body (Standard or Advanced), a PosiTector DPM environmental probe, and a choice of PosiTector 6000 coating thickness probe based on your substrate type, thickness range, and probe style.
- Primary job: Measure coating thickness, document environmental conditions, and record surface profile for coating inspection and reporting
- Surface profile options:
- SPG probe kits: PosiTector SPG surface profile probe included (order codes without RT)
- Testex kits: Testex Digital Micrometer plus replica tape included (order codes ending in RT), replaces an SPG probe
- Gage body: Standard or Advanced (Compare Positector Gage/Body features here)
- Environmental probe included: PosiTector DPM
- Coating thickness probe included: PosiTector 6000, selected by kit configuration
- Thickness probe variants:
- Ferrous only: 6000 F, FS, FT, FTS
- Ferrous and non-ferrous: 6000 FN, FNS
- Probe format: integral or cabled (S)
- Measurement range: 0 to 1,500 μm (0 to 60 mils) or 0 to 6 mm (0 to 250 mils), depending on probe
- Replica tape (included with Testex kits only): 1 carton each of Coarse, X-Coarse, and X-Coarse Plus
- What is included: PosiTector gage body, selected PosiTector 6000 thickness probe, PosiTector DPM probe, plus either an SPG surface profile probe or the Testex Digital Micrometer with replica tape
- Order code families:
- SPG probe kits: KITF1, KITF3, KITFS1, KITFS3, KITFT1, KITFT3, KITFTS1, KITFTS3, KITFN1, KITFN3, KITFNS1, KITFNS3
- Testex kits: KITF1RT, KITF3RT, KITFS1RT, KITFS3RT, KITFT1RT, KITFT3RT, KITFTS1RT, KITFTS3RT, KITFN1RT, KITFN3RT, KITFNS1RT, KITFNS3RT
Additional accessories included in each kit:
- Instruction manuals
- Certificate of calibration
- Non-certified shim set and 220 mil block (order specific)
- Non-certified metal shim and glass zero plate (SPG only)
- Lanyard
- Protective holster
- USB cable
