XHF Top Feed Airless Spray Gun

SKU: GR26C793

Graco XHF Top Feed Airless Spray Gun

Designed to spray high-viscosity paint and coatings. The Graco XHF Top-Feed Gun is easy to maintain, rugged and reliable.

The enhanced versatility of the Graco XHF Top Feed Airless Spray Gun is highlighted by a top entry port. Perfect for projects that require the hose entry vertically, maximizing efficiency and reducing fatigue.

Description

APPLICATIONS:
* Manhole Coating rehabilitation projects
* For epoxy intumescent fireproofing coatings

High-flow, high pressure gun
Handles epoxy intumescent materials, high-viscosity coatings, fiber-filled materials
Top-fed fluid inlet allows easy coating application for below ground-level projects.

TECHNICAL SPECIFICATIONS:
Applicator Type: Manual
Compatible Material: Epoxy Intumescent Fireproofing
Fluid Inlet Size (in): 3/8″
Fluid Inlet Thread: Male
Fluid Inlet Thread Type:NPT
Fluid Orifice Size (in): 0.125
For Use With: Protective Coating High-Pressure Equipment
Gun Activation: Manual trigger
Gun Included: 1
Gun Type: Airless Gun
Gun Weight (lb): 1.6
Gun Weight (oz): 26
Includes: XHD RAC Guard, XHD429 SwitchTip
Maximum Fluid Pressure (psi): 7250
Maximum Fluid Working Pressure (psi): 7250
Overall Height (in): 7.0
Overall Length (in): 8.25
Product Type: Spray Gun
Purge Method: Liquid
Sound Power Level (dB(A)): 93
Sound Pressure Level (dB(A)): 84
Spray Pattern: Flat
Trigger Lock: Locking
Trigger Type: Full-Hand
Type: Spray Gun
Wetted Parts: Tungsten Carbide, 17-4PH Passivated Stainless Steel, Polypropylene, Polyethylene

Graco 26C793

Ask BlastOne representative for how this product can work on your next project.

Document Downloads

XHF Spray Gun Operation Manual
